Acrylonitrile Butadiene Styrene Carrier Tape
Sinho’s ABS (Acrylonitrile Butadiene Styrene) conductive carrier tape offers good strength and stability over time and temperature variations in accordance with EIA-481-D standards. The strength of this material is better than polystyrene (ps), so it provides an economical alternative to Polycarbonate (PC) material.
This material is highly optimized for small pockets for widths of 8mm and 12mm, it is suitable for high volume carrier tape at pre-detemined standard reel lengths. ABS conductive material utilize rotary forming processing to satisfy different applications from customer’s demands, particularly engineered for small pocket designs. If you think PC material cost is too high, this material will be a economical alternate to save your cost. Both single-wind and level-wind are suitable for this material in corrugated paper and plastic reel flanges.
Details
| Suitable for small pockets | Good strength and stability make it become an economical alternative to Polycarbonate (PC) material | Optimized for widths in 8mm and 12mm tape | ||
| Compatible with Sinho Antistatic Pressure Sensitive Cover Tapes and Sinho Heat Activated Adhesive Cover Tapes | Single-wind or level-wind for your choice. | 100% in process pocket inspection |
Typical Properties
| Brands |
SINHO |
||
|
|
Color |
Black |
|
|
|
Material |
Acrylonitrile Butadiene Styrene (ABS) |
|
|
|
Overall Width |
8 mm, 12 mm |
|
|
|
Package |
Single wind Or Level wind format on 22” cardboard reel |
Physical Properties
|
Physical Properties |
Test method |
Unit |
Value |
|
Specific Gravity |
ASTM D-792 |
g/cm3 |
1.06 |
|
Mechanical Properties |
Test method |
Unit |
Value |
|
Tensile Strength @Yield |
ISO527 |
Mpa |
45.3 |
|
Tensile Strength @Break |
ISO527 |
Mpa |
42 |
|
Tensile Elongation @Break |
ISO527 |
% |
24 |
|
Electrical Properties |
Test method |
Unit |
Value |
|
Surface Resistance |
ASTM D-257 |
Ohm/sq |
104~6 |
|
Thermal Properties |
Test method |
Unit |
Value |
|
Heat distortion temperature |
ASTM D-648 |
℃ |
80 |
|
Molding shrinkage |
ASTM D-955 |
% |
0.00616 |
Shelf Life and Storage
Product should be used within 1 year from the date of manufacture. Store in its original packaging in a climate-controlled environment where temperature ranges from 0~40℃, relative humidity <65%RHF. This product is protected from direct sunlight and moisture.
Camber
Meets current EIA-481 standard for camber that is not greater than 1mm in 250 millimeters length.
Cover Tape Compatibility
| Type |
Pressure Sensitive |
Heat Activated |
|||
| Material |
SHPT27 |
SHPT27D |
SHPTPSA329 |
SHHT32 |
SHHT32D |
| Polycarbonate (PC) |
√ |
√ |
x |
√ |
√ |
